Carrier Aura Inverter

Nominal Size

1.0 Hp

1.5 Hp

2.0 Hp

2.5 Hp

MODEL CODES

Set

53CEP009308

53CEP0012308

53CEP0018308

53CEP024308

Indoor Unit

42CEP009308

42CEP0012308

42CEP0018308

42CEP024308

Outdoor Unit

38CEP009308

38CEP012308

38CEP018308

38CEP024308

Power Supply

230V – 60Hz -1Ph

230V – 60Hz – 1Ph

230V – 60Hz – 1Ph

230V – 60Hz -1Ph

Cooling Capacity

9,500(2,930-12,000) kJ-hr

12,700(2,110-14,000) kJ-hr

18,990(4,610-20,000) kJ-hr

25,500(10,850-33,000) kJ-hr

Power Input

560(200-860)W

865(130-1150)W

1,295(290-1560)W

1,650(650-2,600)W

CSPF

6.4

6.5

6.1

6.4

Refrigerant

R32

R32

R32

R32

Sound Level (H/M/L)

35.5/29.5/26.5 dB(A)

37.5/32.5/29.0 dB(A)

41.0/45.0/23.0 dB(A)

44.5/40.0/23.0 dB(A)

PHYSICAL DATA (INDOOR UNIT)

Net Dimension

795*225*295mm

795*225*295mm

965*239*319mm

1140*275*370mm

Gross Dimension

870*370*305mm

870*370*305mm

1045*400*325mm

1230*455*355mm

Net / Gross Weight

10.3/13.1kg

10.3/13.1kg

12.3/16.4kg

20.0/25.3

PHYSICAL DATA (OUTDOOR UNIT)

Net Dimension (W*D*H)

765*303*555mm

765*303*555mm

890*342*673mm

890*342*673mm

Gross Dimension (W*D*H)

887*337*610mm

887*337*610mm

995*398*740mm

995*398*740mm

Net / Gross Weight

22.7/25.2kg

24.3/26.6kg

38.8/41.9kg

45.6/48.8kg

PIPING

Liquid

6.35mm(1/4in)

6.35mm(1/4in)

6.35mm(1/4in)

9.52mm(3/8in)

Gas

9.52mm(3/8in)

9.52mm(3/8in)

12.7mm(1/2in)

15.9mm(5/8in)

Max. Refrigerant Pipe Length

25

25

30

40

Max. Difference in Level

10

10

20

25
